G9916 10 Ton Cable Pulling Machine (Hydraulic Drum Trailer), Wire Length 1000M
G9916 10 Ton Cable Pulling Machine (Hydraulic Drum Trailer), Wire Length 1000M
Features
- Maximum Traction 40 kN
- Traction Speed 0 - 22 m/min (stepless)
- Maximum Working Pressure 22 MPa
- Wire Rope Capacity 650 m
- Diesel Engine Model 2105G4
Scope of Delivery
- Hexagonal wrenches (4/5/6 mm)
- Adjustable wrench (300x36 mm)
- Double-ended wrenches (24x27 / 30x32 / 36x41 mm)
- Pressure oil tank
- Sliding tongue (G9916-9-104)
- Sliding bearing (COB01-3230)
- User manual and product inspection certificate included
FEATURES & APPLICATION
Features
- Single-axle trailer structure - well-arranged layout, convenient operation and flexible transfer
- Premium components - hydraulic parts and diesel engine from well-known brands
- Integrated length metering device - traction length readable directly from counter
- Hydraulic transmission with stepless adjustable traction speed and overload protection
- Automatic rope arrangement system for uniform cable winding
- null manufacturer's warranty
TECHNICAL SPECIFICATIONS
- Maximum Traction 40 kN
- Traction Speed 0 - 22 m/min (stepless)
- Maximum Working Pressure 22 MPa
- Wire Rope Capacity 650 m
- Diesel Engine Model 2105G4
- Engine Rated Power / Speed 24 kW / 2200 rpm
- Engine Cooling Method Water-cooled
- Engine Starting Method Electric start
- Traction Wire Rope 6x37+IWR-phi11-1770 MPa
- Tire Model 205R14-8
- Power Supply DC 24V
- Hydraulic Pump Model A10V028DFR/31RPPA12N00
- Hydraulic Pump Rated Pressure 25 MPa
- Hydraulic Pump Displacement 28 ml/r
- Hydraulic Motor Rated Pressure 25 MPa
- Hydraulic Motor Displacement 250 ml/r
- Hydraulic Oil Grade L-HM46 Anti-wear Hydraulic Oil
- Hydraulic Oil Capacity 130 L
- Gearbox Oil Industrial Gear Oil (40 L)
- Overall Dimensions (L x W x H) 3725 x 1600 x 1650 mm
- Overall Weight 2000 kg
